genetic-sudoku

genetic-sudoku is a Rust program designed to solve Sudoku puzzles using a multithreaded genetic algorithm.

Usage

Usage: genetic-sudoku [OPTIONS] <BOARD_PATH>

Arguments:
  <BOARD_PATH>  Path to board file

Options:
  -p, --population <POPULATION>
          Population per generation [default: 100]
  -s, --selection-rate <SELECTION_RATE>
          Fraction of population selected [default: 0.5]
  -m, --mutation-rate <MUTATION_RATE>
          Mutation rate as fraction [default: 0.06]
  -r, --render <RENDER>
          Number of generations between screen renders. Higher values give better computational performance
  -h, --help
          Print help
  -V, --version
          Print version

A Sudoku puzzle board file contains a textual matrix of values, with 0 representing empty cells in the puzzle, and non-zero values representing the numbers given in the puzzle. The current source code deals only with 9×9 Sudoku puzzles; the constant BOARD_SIZE in src/main.rs can be changed for other puzzle sizes. The boards/ directory contains a variety of puzzle boards.

The --population, --selection-rate, and --mutation-rate arguments specify the parameters used in running the genetic algorithm described below. There are sensible defaults for all of these. Note that the "fraction" arguments expect a floating-point number between 0.0 and 1.0.

The optional --render argument specifies the number of generations between screen renders. The higher the value the less often the screen will be rendered with updates, allowing more CPU time for running the simulation.

How It Works

• Generate a random population of potential solutions
• For each potential solution:
  • "Overlay" the potential solution on top of the base board we're looking to solve for by only replacing the base board's 0 cells
  • Evaluate the "fitness" of the potential solution by summing the number of duplicated values in each row, column, and box, to produce a fitness score. The lower the fitness score, the better the solution. A fitness score of 0 is a valid solution to the puzzle
• With all the potential solution fitness scores calculated:
  • Sort them and apply "natural selection" to filter out only the top percentage determined by --selection-rate
  • Group the remaining potential solutions into pairs
  • Have each pair produce enough children to create the next generation's population of potential solutions
    • When each child is created, for each value there is a chance determined by --mutation-rate to randomly "mutate" and generate a whole new value
    • If the value is not mutated, there is a 50% chance to "inherit" the value from one parent and a 50% chance to "inherit" from the other parent
• Loop this process until a valid solution is found

Acknowledgements

The Sudoku boards in boards/mantere-koljonen are from:

Mantere, Timo and Janne Koljonen (2008). Solving and Analyzing Sudokus with Cultural Algorithms. In Proceedings of 2008 IEEE World Congress on Computational Intelligence (WCCI 2008), 1-6 June, Hong Kong, China, pages 4054-4061.

Made available here.

Thanks much to the authors for collecting these.

The Al Escargot board is by Arto Inkala.
