Incorrect results for a couple of real cpp_bin_float functions:ℝ→ℝ

[cosurgi]

As requested I am opening another issue for problems with following functions, but only for cpp_bin_float real valued functions:

• sin, cos, tan with 7e7 ULP error
• acos with 10000 ULP error
• erfc with 20000 ULP error
• lgamma with 70000 ULP error (edited)
• tgamma with 10000 ULP error
• fma with 2e5 ULP error

I prepared std::vector<std::string> suspects = {……} so that only these arguments are tested. So I'm sorry that this test program is a little longer. I can push it somewhere via git if you want.

@jzmaddock said
Yes please. Note however that most of those functions have regions that are ill-conditioned. I'm surprised about erf though.

So I do a domain check in the code below, but that's just the domain check via mathematical definition of the function. E.g. acos in (-1,1) range. But if there are some wider ill-conditioned cpp_bin_float ranges then you tell me what are those :)

The last couple tests are done on MPFR types, to show that they have no problems, even when I reduce the tolerance to 4 ULP.

This test is done on g++-10 and Boost 1.71

#include <boost/core/demangle.hpp>
#include <boost/multiprecision/float128.hpp>
#include <boost/multiprecision/mpfr.hpp>
#include <boost/multiprecision/cpp_bin_float.hpp>
#include <iostream>
#include <string>
#include <vector>

// these suspects that I found here were generated with 207 (semi-random) bits, cpp_bin_float<62> that is.
std::vector<std::string> suspects =
{
"-99.99051044261190803828277871209611083521312159772951785429282742447111501770387897764914459929030895961457916310906347977088468929912075917569999182149214394708068576189674558918341062963008880615234375",
"-99.23390959446626271324034474274442251884471237189555648094657059216860706607230983323106368424801631883935026863224574760130807307771805691417887408046384289874060347091955236464855261147022247314453125",
"-98.9601713316877088337177445119470740578579166310219652750338812970411599649857990095222187693902055061636695929602719448563570542635141882380804268308514937244231568502783602525596506893634796142578125",
"-98.273813022182876335674961215978389185880158614907235514650235867554610737475054142604330810869605796963554540686259410168473190820224120735175598211787517991498697167429554610862396657466888427734375",
"-98.1129673249056279651265099215966864727359600855606270412253136392329234530313794427136637055560221800456208046576431258117530821299909173847892873020493030816573110097777998817036859691143035888671875",
"-97.389369764346678086481891064814826474831092962567795459730881505082734698449439138689254963656701672933811803557867845743694253575567006314050085743567864815344037321409587093512527644634246826171875",
"-95.81857221869257960935742769742992913057780233194018961846245753236156690762799658755131314850200998334040944803550122736063078540309929170741814952093887546176985414714266653390950523316860198974609375",
"-92.41884548834482351580942729503268036653297534861723287901036113912045650063200397203449032796157971583666591400004045975989150366281884624802662149806202205909629043834030426296521909534931182861328125",
"-91.1061877200439407432384615462896541336997550990506594144915374189322511915338633133119583121624515660791329437500227666881849937355906834387488978756948848299924981208874896765337325632572174072265625",
"-89.88901025192110738330790618249721807309639606773637313381141814624705166266602211251904155822175375028221083070595793995144725917986725146484809181158549739264727873599980512153706513345241546630859375",
"-89.5353901456268146780894922808504683043625998859211699302844699006615833786787620155903405554436561863769757162466938403503598928733212929892185960036262953160544897368566807926981709897518157958984375",
"-82.1735520704620443988984953466372698685913582823295765947054351112482828444196668754236587930583613773862145085498288866696315110855282598447092727081999454104808966459216890143579803407192230224609375",
"-77.4823796790540815922431050434539860561416780588691652960638531675828303613178820006138086077402642358169796090547340159455478668941626522124178433128328640096781076973542212726897560060024261474609375",
"-76.99175113943655525504236511759596519945485974092039507047416560034531419571148155966846401745208762372457862829213996244244865281367459385377136496207263084289203203258722396640223450958728790283203125",
"-74.61255333976712083091879675534822922304761149616407008730070078988643083933215168414352880237541830345893825991799418214718663934337361280342675580186924961102572229076912435630219988524913787841796875",
"-72.3148104470242378111131793549028166185391566893773764561918781174851603967015597324961371802863065721050633633189851030237069974043738081738156836369644443643193987281136969613726250827312469482421875",
"-65.6435462795664662509771573366666549161813140877948752939617569007726832786509545361560456448812909391572172265680384625360761114969384119631392422215792126281679041976957478254917077720165252685546875",
"-58.1194637727400116282382861620192645168456286573655292854115447804934531033530825341470365817522667175865233641660823248322056381392871614104021682035650111738424306029315857813344337046146392822265625",
"-46.00377253908153163234835861938988189011724937250550191704727440078450345533379528244871632668899992466976676697133833647564925859881415224025606188892635798714896011585295809709350578486919403076171875",
"-44.4018537144116355553957796775986930181198953013070477698158368990850213417187435014923789688670795285241686594695650800353491215038601488478780249088234035183091197307447828279691748321056365966796875",
"-42.178867533615277746638335956312648788666574058754668089030698639143496696692892419393689512323455361357823651939047406700172638876986456164277459200305282980007944015898857514912378974258899688720703125",
"-37.463814793675275461340264701880657547498904997758234907382436644440387185383888069692093701283418496171812743486767600476345326829809773758398740227733327893774352423950091406368301250040531158447265625",
"-36.687894664533810937311533733623204481210731875314969097117453723702620271139130018679051998429836998807714049077719477378387717033200220973951746780027503998765359138900521429604850709438323974609375",
"-28.64389272279336971899833313469911474439779953887602880275372619043693669817718560048422360489311115432830897163631478540521766172994972680472028686375514700446394400490390808045049197971820831298828125",
"-28.0049139189336880614936157837694875795078481812590699169249409778955821694343725412388088298559665974798192998478183283974952859016032716608150750782873554208841915258432209157035686075687408447265625",
"-26.27180763553655086974675201041863634842370354443985880608654015680918608411304588751537996354581477114994399729425244435651959022879036487160686066081892033421442411711410613861517049372196197509765625",
"-25.19589620543179814909094172303432814133713508768451885201830602238490586082017718958403502211165076000022756274322670476508649605244189795114035788739250985098123980510109731767443008720874786376953125",
"-25.13274460509201434480266058335104919728710461006166448957435054060930768882685992519312501100646264865618197931948935269332644328253058412301382409241950447072178054241931022261269390583038330078125",
"-24.3953393891403751990434066978288339384375573172866562212210641433035459991358198899245580781841692398778762926576347126875939333921008840292697330648373870679197772393109744371031410992145538330078125",
"-21.09522851245033636306402211225949554094174191622852088230859853405429426073319491152815162110789708135363180731077163134358817681937892456607698197182937716368487934825992624610080383718013763427734375",
"-18.99938574552839199324805802310536938840417940528040264994230879127715234997780930686638661213255462498806211545865983339025364050801922290465869751649067992947152172522606861093663610517978668212890625",
"-16.1054921663428825424335275871979183815357076427275834397442882246577003003947573289675799854994087290464911637642925175788912463196112911507347146483208575619937297229711248292005620896816253662109375",
"-15.73606255635348930406430675898903077327778525123481926630706457480564768230418298855932815114879596305648746566826709238793635624816065807957821140335105770187602847176577824939158745110034942626953125",
"-13.844342695544957837434025971838094757130400709693375931013384200015240921794309640808969294106787118008983305677558784686668901577262469676705839997599836797663452880868817373993806540966033935546875",
"-12.0108256663021959292221821504924285077679894795415928058870037494381092873899810180946465666595655424900842675906679066861586687873299236208804084527982847696754575839150902538676746189594268798828125",
"-10.00031013274038195290023947364801980860573336384093125993165793242441917674719101901475578381172139328538478579821165445665430869130966779506355287008010477201210008946219431891222484409809112548828125",
"-8.00002606729166538824643828246571667601957528380422187224925264792051768683947293015968599171373933233014603623537359584513425170094804665935239384252086272957156520835297897065174765884876251220703125",
"-6.00136682225492754251204662283943131239849406671099109862729681998415655896338341898554616420963838467993260300566362082682688543052932950197434420055032149531569485301218946915469132363796234130859375",
"-4.03935176182968248850425274573197268040942586626526838633754467790994461640466129194118835598340118294709330113984308095784822410899225766569451949983317611166111493758990036440081894397735595703125",
"-3.0240920288930329988980374744242432174547781269616617810591667842849794114087483433483690367847145810986439948789823331633666322045350227369058242087843354551669750041043016608455218374729156494140625",
"-2.45703434083386998275925378730707853886429974961703191606644158840534757638881189433235828818780863495008551032003814937228673471251368171994648347271862826902977250398407704778946936130523681640625",
"-2.45702409322290866567069073111226123857093891190759763630180185440854570661779988634018746783189304594656392773180501945370983941166634220688688556283277257129456228046393562181037850677967071533203125",
"-1.68169675859976659383108338072526819755655584974521789613087401183387429879714920504893731220566066433092139915659379637884440972895014577991321577305253685830077614582478418014943599700927734375",
"-0.8282564029863776126578656468289904548301926008360850725607385349535211657160850878019333716199903358537998263735956441731642451949396509520995591712819820502493317615488876981544308364391326904296875",
"-0.32136064705709597454683625174723961593146173639012134904467758003590583919808930814050545965484123350604583749902317747452315051081556469722141906597624489046183260398947822977788746356964111328125",
"0.46721644973365601360133602238548895907862098406622072706034309566800215546218584935514980265179575405374460581236738760590882160438856238290914946721340585134019107726999209262430667877197265625",
"0.999846935115256985099472087619410059034039136463602141692454832980536542150610828088069585167055187023555569404437106928970332167071435310425941385031029895284759856366463282029144465923309326171875",
"0.99988767201274738245735086136368521485585806605382659983192152902696406932008939599756249510654260590532728278579290850296943869294248260415662522058393880540656806221733177153510041534900665283203125",
"0.999890658691280253459563000177154110549643009678046768723093809280489994853890555289525263351943778362525321014124545828049510733153266589198126845022007746534298266993801007629372179508209228515625",
"0.999890866630185914587046276951054077223882235976803551094669700127799173507869538140351795204645068157857366025341530654308963466229817646946295966864834393016125968500773524283431470394134521484375",
"0.9998935834632539389432532416679314303104944098437646169936959501208480776770549549396436304932167485457590024069924603839254637269127683893329896050425928226423888389717831159941852092742919921875",
"0.9998937078809612793196456117613076238607542194482800109271476030303818189373028927817720019485705963490501809249485198842139120807378682861591436713538045611728011241581270951428450644016265869140625",
"0.9998938266238835248172237531591128278247832584171582274981000092413549795680158553547781577679123233133582668576009454540078156352860532955582650147430441578411119962765951640903949737548828125",
"1.31807073864746745220380666020953425708782839063532147724215402784222028983184986695417973418596170725423236711281442200052112002936531018527445826575889803824494228567942855079309083521366119384765625",
"2.05118616373376822351059060334033552537053819234188264727312593977696266313461209366740347658511550317741748782578284208029622842257369906721179886195782958121548722463245439939782954752445220947265625",
"14.81907944221615795927300817825273323995258820785195324332346982881369733699449486066221176276821157545838038881434799007345102544573284121878574555603790032496692996577536405311548151075839996337890625",
"28.86382646919547451704802146558570204667176129200120383736328754193446432280602654739983984395786925252355041424685510746821564041731449426350230758472895022277715515457430228707380592823028564453125",
"37.714117388111989956041102504146323181250085280470547904334284311710392522527934075592357284175540227603002107141232187606083931450205311188420619775073138932840188797257496844395063817501068115234375",
"37.755692600976890509060126539791454024057262140474811481640356032121125141911161464415653798084260615297277298486172253135984357874602234962374017127404099967470652021717114621424116194248199462890625",
"43.1803311978604564169383897713532689475466446393217746344408051982016068191582531106463642440364694513352131182034723647935400394961893836912807402147128875424808569505330524407327175140380859375",
"44.8136269782289928625179989261586968859704136307989349216436641020178036768807849394357169505890377033019777761450383475357716008285913212762440013978080310193437274524086433302727527916431427001953125",
"47.7466833592842141724124786289501525735591596956904479800788632710915981013637380490409808488674608936498347095426906680888360693051845194282363447716043526277730768558882346042082644999027252197265625",
"48.5373479167760837984751589435425712042885137507272816756492359179219111789370782710753352832578889227710125612304041008705021198073669031963387872820418281736599974696133585894131101667881011962890625",
"50.2654237499756733391222254122805320113428095281996770142576041928720328847038073008540751164256335141210504687992703586601047641219781397261165193341597270449729040198150187279679812490940093994140625",
"66.475153220534004851292526233200206437375861594380699566663661143294973948983537723870961684073064116387026367864722840661735428670419848958023413614398867727169062380454533922602422535419464111328125",
"81.6813903871233164206231157958374137736575469952408038962124876646551135758586852641465094333999801948744979304163225462391891136623683615941281815737538089523643580758260895890998654067516326904296875",
"90.5055529204410608252721620806883201091798030906746366296219309300593773762484102001340104622297142486139344072193634452555957932797466287389178621999435495602305545848054180169128812849521636962890625",
"91.1061928073599934918157143693445377704705143712968984369886992676466700842560738586081200771883133480499146932659993234293192141302496948118607650536006329505291090331553505166084505617618560791015625",
"91.73096013967822637902416462228509184659994913333375698315287016094450586596998400386341289481248526500038762543132207961366660355580285937087410175116695986753667657609412344754673540592193603515625",
"96.006219145174968389135648559819121058721694089272516452196945753282582422246476865909482984419546829495310684769521880110885806790842600551509460451587668161459176996430642248014919459819793701171875",
"97.389368411290298402830640798173079547959579858387300352046564554983962377373474417232814245397912161320988898124674543550781585423318179803285572760545009906273106192742261555395089089870452880859375",
"98.0989550614355490188345206791598701919776512387165808297572266422581898406437029731615350650185511553954839433926255993281461118980368400993687322616830094970143127941497596111730672419071197509765625",
"98.96015456301280320862779505809196791836643290291948125688893156142059072001012434950259767595461620194995593174473903568075803746371943076148585708991150589920737790095017771818675100803375244140625",
"99.215809318714254781755417250857229813252158084760395373122363660557432217805933289849573751176675695362239479172525090760908689972963504911406316481201661289408832988812037001480348408222198486328125",
"99.526174807950546775689149433642956463205915643028662653550636461692965655300301728228212687122980789586022357026446091170053596694888030662864493749047536713843442601756805743207223713397979736328125"
};

std::vector<std::string> fma_suspects =
{"-65.6435462795664662509771573366666549161813140877948752939617569007726832786509545361560456448812909391572172265680384625360761114969384119631392422215792126281679041976957478254917077720165252685546875",
"-21.09522851245033636306402211225949554094174191622852088230859853405429426073319491152815162110789708135363180731077163134358817681937892456607698197182937716368487934825992624610080383718013763427734375",
"1.31807073864746745220380666020953425708782839063532147724215402784222028983184986695417973418596170725423236711281442200052112002936531018527445826575889803824494228567942855079309083521366119384765625",
"37.755692600976890509060126539791454024057262140474811481640356032121125141911161464415653798084260615297277298486172253135984357874602234962374017127404099967470652021717114621424116194248199462890625",
"0.46721644973365601360133602238548895907862098406622072706034309566800215546218584935514980265179575405374460581236738760590882160438856238290914946721340585134019107726999209262430667877197265625",
"43.1803311978604564169383897713532689475466446393217746344408051982016068191582531106463642440364694513352131182034723647935400394961893836912807402147128875424808569505330524407327175140380859375",
"-0.8282564029863776126578656468289904548301926008360850725607385349535211657160850878019333716199903358537998263735956441731642451949396509520995591712819820502493317615488876981544308364391326904296875",
"-82.1735520704620443988984953466372698685913582823295765947054351112482828444196668754236587930583613773862145085498288866696315110855282598447092727081999454104808966459216890143579803407192230224609375",
"-3.0240920288930329988980374744242432174547781269616617810591667842849794114087483433483690367847145810986439948789823331633666322045350227369058242087843354551669750041043016608455218374729156494140625",
"44.8136269782289928625179989261586968859704136307989349216436641020178036768807849394357169505890377033019777761450383475357716008285913212762440013978080310193437274524086433302727527916431427001953125",
"37.714117388111989956041102504146323181250085280470547904334284311710392522527934075592357284175540227603002107141232187606083931450205311188420619775073138932840188797257496844395063817501068115234375",
"-77.4823796790540815922431050434539860561416780588691652960638531675828303613178820006138086077402642358169796090547340159455478668941626522124178433128328640096781076973542212726897560060024261474609375",
"-1.68169675859976659383108338072526819755655584974521789613087401183387429879714920504893731220566066433092139915659379637884440972895014577991321577305253685830077614582478418014943599700927734375",
"48.5373479167760837984751589435425712042885137507272816756492359179219111789370782710753352832578889227710125612304041008705021198073669031963387872820418281736599974696133585894131101667881011962890625"};


template <typename Type, typename Reference, typename Tol> void test(Tol tolerance)
{
	std::cout << "\n========================\nTesting:\n   " << boost::core::demangle(typeid(Type).name()) << " against:\n   " << boost::core::demangle(typeid(Reference).name()) << "\n";
	for (const auto& str : suspects) {
		//std::cout << str << "\n";
		Type      arg_1(str);
		Reference arg_ref_1(str);
		if ((arg_1 != static_cast<Type>(arg_ref_1)) or (static_cast<Reference>(arg_1) != arg_ref_1)) {
			std::cout << "These are different numbers, cannot work with that. It is because 'suspects' were prepared with 207 semi-random bits, 62 decimal places that is. Some extra cutting and "
			             "casting could be done here to fix this.\n";
			exit(1);
		}
		/* skip extra cutting and casting, I didn't test that.
		if ((arg_1 != static_cast<Type>(arg_ref_1)) or (static_cast<Reference>(arg_1) != arg_ref_1)) {
			arg_1     = static_cast<Type>(arg_ref_1);
			arg_ref_1 = static_cast<Reference>(arg_1);
		}*/

#define TEST_FUNCTION(func)                                                                                                                                  \
	{                                                                                                                                                    \
		Type      val_1     = boost::multiprecision::func(arg_1);                                                                                    \
		Reference val_ref_1 = boost::multiprecision::func(arg_ref_1);                                                                                \
		if (boost::multiprecision::isfinite(val_1) and (boost::multiprecision::isfinite(val_ref_1))) {                                               \
			auto ulp = boost::math::float_distance(static_cast<Type>(val_ref_1), val_1);                                                         \
			if ((ulp > tolerance) or (ulp < -tolerance)) {                                                                                       \
				std::cout << std::setw(7) << #func << " ULP dist = " << std::setw(15) << ulp << "   argument = " << arg_1 /* str */ << "\n"; \
			}                                                                                                                                    \
		} else if ((boost::multiprecision::isfinite(val_1) and (not(boost::multiprecision::isfinite(val_ref_1))))) {                                 \
			std::cout << std::setw(7) << #func << "  : lower precision is a finite value, higher isn't (only the opposite makes sense)"          \
			          << "   argument = " << arg_1 /* str */ << "\n";                                                                            \
		}                                                                                                                                            \
	}

		TEST_FUNCTION(sin)
		TEST_FUNCTION(cos)
		TEST_FUNCTION(tan)
		// acos domain check (-1,1)
		if ((arg_1 > static_cast<Type>(-1)) and (arg_1 < static_cast<Type>(1))) {
			TEST_FUNCTION(acos)
		}
		TEST_FUNCTION(erfc)
		// gamma domain check skip negative integers
		if (not((arg_1 < 0) and (static_cast<Type>(boost::multiprecision::round(arg_1)) == arg_1))) {
			TEST_FUNCTION(tgamma)
			if(boost::multiprecision::tgamma(arg_1) > 0 ) {
				TEST_FUNCTION(lgamma)
			}
		}
		// I just copy that macro, but function fma(…,…,…) uses three args
		for (const auto& str2 : fma_suspects) {
			Type      arg_2(str2);
			Reference arg_ref_2(str2);
			for (const auto& str3 : fma_suspects) {
				Type      arg_3(str3);
				Reference arg_ref_3(str3);
				{
					Type      val_1     = boost::multiprecision::fma(arg_1, arg_2, arg_3);
					Reference val_ref_1 = boost::multiprecision::fma(arg_ref_1, arg_ref_2, arg_ref_3);
					if (boost::multiprecision::isfinite(val_1)) {
						auto ulp = boost::math::float_distance(static_cast<Type>(val_ref_1), val_1);
						if ((ulp > tolerance) or (ulp < -tolerance)) {
							std::cout << std::setw(7) << "fma"
							          << " ULP dist = " << std::setw(15) << ulp << "   argument = " << arg_1 << " , " << arg_2 << " , " << arg_3 /* str, str2, str3 */ << "\n";
						}
					}
				}
			}
		}
	}
	std::cout << "DONE\n";
#undef TEST_FUNCTION
}

int main()
{
	test<boost::multiprecision::number<boost::multiprecision::cpp_bin_float<62>, boost::multiprecision::et_off>, boost::multiprecision::mpfr_float_500>(10000);
	test<boost::multiprecision::number<boost::multiprecision::cpp_bin_float<62>, boost::multiprecision::et_off>,
	     boost::multiprecision::number<boost::multiprecision::cpp_bin_float<124>, boost::multiprecision::et_off>>(10000);
	test<boost::multiprecision::number<boost::multiprecision::cpp_bin_float<62>>, boost::multiprecision::mpfr_float_500>(10000);

	// MPFR works
	test<boost::multiprecision::number<boost::multiprecision::mpfr_float_backend<62, boost::multiprecision::allocate_stack>, boost::multiprecision::et_off>, boost::multiprecision::mpfr_float_500>(4);
	test<boost::multiprecision::mpfr_float_100, boost::multiprecision::mpfr_float_500>(4);

	// we might test these later too. Won't work now, because suspects data was prepared for 62 decimal places.
	//test<boost::multiprecision::float128, boost::multiprecision::mpfr_float_50>(4);
	//test<boost::multiprecision::mpfr_float_50, boost::multiprecision::mpfr_float_100>(4);
}

EDIT: Here's my (fixed lgamma domain) output:

========================
Testing:
   boost::multiprecision::number<boost::multiprecision::backends::cpp_bin_float<62u, (boost::multiprecision::backends::digit_base_type)10, void, int, 0, 0>, (boost::multiprecision::expression_template_option)0> against:
   boost::multiprecision::number<boost::multiprecision::backends::mpfr_float_backend<500u, (boost::multiprecision::mpfr_allocation_type)1>, (boost::multiprecision::expression_template_option)1>
    cos ULP dist =    -1.05074e+07   argument = -98.9602
    tan ULP dist =     1.01564e+07   argument = -98.9602
    sin ULP dist =    -1.67319e+07   argument = -97.3894
    tan ULP dist =     1.67319e+07   argument = -97.3894
    cos ULP dist =      1.6665e+07   argument = -95.8186
    tan ULP dist =     8.78195e+06   argument = -95.8186
    sin ULP dist =      4.3195e+07   argument = -91.1062
    tan ULP dist =     -4.3195e+07   argument = -91.1062
    cos ULP dist =    -1.82969e+07   argument = -89.5354
    tan ULP dist =    -3.58613e+07   argument = -89.5354
    cos ULP dist =     5.33625e+07   argument = -58.1195
    tan ULP dist =     5.97394e+07   argument = -58.1195
    fma ULP dist =           15802   argument = -28.6439 , 1.31807 , 37.7557
    sin ULP dist =     1.07071e+06   argument = -25.1327
    tan ULP dist =     1.07071e+06   argument = -25.1327
 tgamma ULP dist =          -10271   argument = -15.7361
    fma ULP dist =         -194768   argument = -0.321361 , -65.6435 , -21.0952
   acos ULP dist =          -10075   argument = 0.999891
 lgamma ULP dist =           13963   argument = 1.31807
    fma ULP dist =          -26108   argument = 14.8191 , -3.02409 , 44.8136
    sin ULP dist =         -527053   argument = 50.2654
    tan ULP dist =         -527053   argument = 50.2654
    sin ULP dist =    -1.74569e+06   argument = 81.6814
    tan ULP dist =    -1.74569e+06   argument = 81.6814
    sin ULP dist =    -5.39938e+06   argument = 91.1062
    tan ULP dist =     5.39938e+06   argument = 91.1062
   erfc ULP dist =           20408   argument = 91.731
   erfc ULP dist =           22029   argument = 96.0062
    sin ULP dist =     8.36595e+06   argument = 97.3894
    tan ULP dist =    -8.36595e+06   argument = 97.3894
   erfc ULP dist =           20748   argument = 98.099
    cos ULP dist =    -2.62684e+06   argument = 98.9602
    tan ULP dist =    -1.55465e+06   argument = 98.9602
   erfc ULP dist =           21844   argument = 99.2158
   erfc ULP dist =           22085   argument = 99.5262
DONE

========================
Testing:
   boost::multiprecision::number<boost::multiprecision::backends::cpp_bin_float<62u, (boost::multiprecision::backends::digit_base_type)10, void, int, 0, 0>, (boost::multiprecision::expression_template_option)0> against:
   boost::multiprecision::number<boost::multiprecision::backends::cpp_bin_float<124u, (boost::multiprecision::backends::digit_base_type)10, void, int, 0, 0>, (boost::multiprecision::expression_template_option)0>
    cos ULP dist =    -1.05074e+07   argument = -98.9602
    tan ULP dist =     1.01564e+07   argument = -98.9602
    sin ULP dist =    -1.67319e+07   argument = -97.3894
    tan ULP dist =     1.67319e+07   argument = -97.3894
    cos ULP dist =      1.6665e+07   argument = -95.8186
    tan ULP dist =     8.78195e+06   argument = -95.8186
    sin ULP dist =      4.3195e+07   argument = -91.1062
    tan ULP dist =     -4.3195e+07   argument = -91.1062
    cos ULP dist =    -1.82969e+07   argument = -89.5354
    tan ULP dist =    -3.58613e+07   argument = -89.5354
    cos ULP dist =     5.33625e+07   argument = -58.1195
    tan ULP dist =     5.97394e+07   argument = -58.1195
    fma ULP dist =           15802   argument = -28.6439 , 1.31807 , 37.7557
    sin ULP dist =     1.07071e+06   argument = -25.1327
    tan ULP dist =     1.07071e+06   argument = -25.1327
 tgamma ULP dist =          -10271   argument = -15.7361
    fma ULP dist =         -194768   argument = -0.321361 , -65.6435 , -21.0952
   acos ULP dist =          -10075   argument = 0.999891
 lgamma ULP dist =           13963   argument = 1.31807
    fma ULP dist =          -26108   argument = 14.8191 , -3.02409 , 44.8136
    sin ULP dist =         -527053   argument = 50.2654
    tan ULP dist =         -527053   argument = 50.2654
    sin ULP dist =    -1.74569e+06   argument = 81.6814
    tan ULP dist =    -1.74569e+06   argument = 81.6814
    sin ULP dist =    -5.39938e+06   argument = 91.1062
    tan ULP dist =     5.39938e+06   argument = 91.1062
   erfc ULP dist =           20408   argument = 91.731
   erfc ULP dist =           22029   argument = 96.0062
    sin ULP dist =     8.36595e+06   argument = 97.3894
    tan ULP dist =    -8.36595e+06   argument = 97.3894
   erfc ULP dist =           20748   argument = 98.099
    cos ULP dist =    -2.62684e+06   argument = 98.9602
    tan ULP dist =    -1.55465e+06   argument = 98.9602
   erfc ULP dist =           21844   argument = 99.2158
   erfc ULP dist =           22085   argument = 99.5262
DONE

========================
Testing:
   boost::multiprecision::number<boost::multiprecision::backends::cpp_bin_float<62u, (boost::multiprecision::backends::digit_base_type)10, void, int, 0, 0>, (boost::multiprecision::expression_template_option)0> against:
   boost::multiprecision::number<boost::multiprecision::backends::mpfr_float_backend<500u, (boost::multiprecision::mpfr_allocation_type)1>, (boost::multiprecision::expression_template_option)1>
    cos ULP dist =    -1.05074e+07   argument = -98.9602
    tan ULP dist =     1.01564e+07   argument = -98.9602
    sin ULP dist =    -1.67319e+07   argument = -97.3894
    tan ULP dist =     1.67319e+07   argument = -97.3894
    cos ULP dist =      1.6665e+07   argument = -95.8186
    tan ULP dist =     8.78195e+06   argument = -95.8186
    sin ULP dist =      4.3195e+07   argument = -91.1062
    tan ULP dist =     -4.3195e+07   argument = -91.1062
    cos ULP dist =    -1.82969e+07   argument = -89.5354
    tan ULP dist =    -3.58613e+07   argument = -89.5354
    cos ULP dist =     5.33625e+07   argument = -58.1195
    tan ULP dist =     5.97394e+07   argument = -58.1195
    fma ULP dist =           15802   argument = -28.6439 , 1.31807 , 37.7557
    sin ULP dist =     1.07071e+06   argument = -25.1327
    tan ULP dist =     1.07071e+06   argument = -25.1327
 tgamma ULP dist =          -10271   argument = -15.7361
    fma ULP dist =         -194768   argument = -0.321361 , -65.6435 , -21.0952
   acos ULP dist =          -10075   argument = 0.999891
 lgamma ULP dist =           13963   argument = 1.31807
    fma ULP dist =          -26108   argument = 14.8191 , -3.02409 , 44.8136
    sin ULP dist =         -527053   argument = 50.2654
    tan ULP dist =         -527053   argument = 50.2654
    sin ULP dist =    -1.74569e+06   argument = 81.6814
    tan ULP dist =    -1.74569e+06   argument = 81.6814
    sin ULP dist =    -5.39938e+06   argument = 91.1062
    tan ULP dist =     5.39938e+06   argument = 91.1062
   erfc ULP dist =           20408   argument = 91.731
   erfc ULP dist =           22029   argument = 96.0062
    sin ULP dist =     8.36595e+06   argument = 97.3894
    tan ULP dist =    -8.36595e+06   argument = 97.3894
   erfc ULP dist =           20748   argument = 98.099
    cos ULP dist =    -2.62684e+06   argument = 98.9602
    tan ULP dist =    -1.55465e+06   argument = 98.9602
   erfc ULP dist =           21844   argument = 99.2158
   erfc ULP dist =           22085   argument = 99.5262
DONE

========================
Testing:
   boost::multiprecision::number<boost::multiprecision::backends::mpfr_float_backend<62u, (boost::multiprecision::mpfr_allocation_type)0>, (boost::multiprecision::expression_template_option)0> against:
   boost::multiprecision::number<boost::multiprecision::backends::mpfr_float_backend<500u, (boost::multiprecision::mpfr_allocation_type)1>, (boost::multiprecision::expression_template_option)1>
DONE

========================
Testing:
   boost::multiprecision::number<boost::multiprecision::backends::mpfr_float_backend<100u, (boost::multiprecision::mpfr_allocation_type)1>, (boost::multiprecision::expression_template_option)1> against:
   boost::multiprecision::number<boost::multiprecision::backends::mpfr_float_backend<500u, (boost::multiprecision::mpfr_allocation_type)1>, (boost::multiprecision::expression_template_option)1>
DONE

[cosurgi]

I should have sorted suspects. After sorting I realized that there are 5 duplicates.

EDIT: I fixed this in OP

[ckormanyos]

I would like to look at a few instances of spurious results for LogGamma[x].

But I have a few questions.

• Are you dealing with real-valued arguments and results?
• Are you interested in (the complex-valued) result of:

N[LogGamma[-58.1194637727400116282382861620192645168456286573655292854115447804934531033530825341470365817522667175865233641660823248322056381392871614104021682035650111738424306029315857813344337046146392822265625`206], 200]

I get a complex value for that one.

[ckormanyos]

The last couple tests are done on MPFR types, to show that they have no problems, even when I reduce the tolerance to 4 ULP.

MPFR can dynamically increase its precision (and the digits in the type at hand) when calculating near singularities. I think most Boost.Math special functions use fixed-width from start to end. So I believe calculations often could get lossy near singularities, unless something like a Taylor series could be found for some of the ranges you suspect.

[cosurgi]

Are you dealing with real-valued arguments and results?

yes, in this test I only work with real valued arguments and results. And thanks, of course lgamma can't work when tgamma is negative! I will edit the code.

(EDIT: OK, I fixed the code in the opening post)

MPFR can dynamically increase its precision [...]

yes, I'm aware of that. We can make these tests pass just by increasing the acceptable ULP error, and this solution is enough for me, because (as I see it) cpp_bin_float is sort of a test/fallback type. I only thought that you would be interested about these (potential) problems.

And also: all other cpp_bin_float common math functions have ULP error < 127. Only these few had problems.

[jzmaddock]

Many thanks for the test cases, working on some error plots now....

[cosurgi]

Many thanks for the test cases, working on some error plots now....

you are welcome. In a few days I will add a couple more suspects :) I only scanned about a half of the target 2e7 cases for each common math so far.

[jzmaddock]

OK, some ULP plots coming up....

acos, asin, atan all look good to me, though if we're being picky atan near zero might be improvable:

acos:

asin:

atan:

[jzmaddock]

sin/cos/tan exhibit the usual high errors near the roots, I do wonder if higher than normal precision for the calculation of N * Pi would be enough to (mostly) squash these:

cos:

sin:

tan:

[jzmaddock]

Log looks good, though I might have hoped for smaller errors on something that's so crazy-well-conditioned:

exp as you would expect gets tougher for larger arguments:

[jzmaddock]

tgamma behaves much as you would expect, especially for larger arguments:

erf looks good, though I wonder if there is low hanging fruit near zero:

erfc has high error for large arguments, but it's ~ e^-x^2 in that domain, so we have the same ill-conditioned issues as exp, but more so:

[NAThompson]

Wow, I'm glad to see these plots work well! (Well, other than the couple bugs you had to fix in #417)

@cosurgi : Note how these plots give a totally different way of understanding accuracy; @jzmaddock notes that erf at zero is inaccurate, but it's only inaccurate relative to the condition number; in fact in absolute terms it is pretty good. Now, there is another philosophy, adopted by MPFR, that for a representable x, f(x) is the correctly rounded value. This generally requires extra precision internally. Now, whether or not that's what you should do for cpp_bin_float is unclear to me, because I don't understand the internals of that class. But generally what you do if you want half-ulp accuracy instead of mere backward stability is that you do some analysis to figure out your extra precision requirements, then you cast the input to a fixed-precision type of the requisite length, perform the algorithm in fixed point, and finally cast back the the floating point type.

I do wonder if higher than normal precision for the calculation of N * Pi would be enough to (mostly) squash these.

This is sort of half-way between the philosophy of MPFR and the backward stability philosophy. I mean, no one would complain if things got a bit more accurate, but at the same time, what is the claimed accuracy in the docs? I believe that the claimed accuracy of cpp_bin_float is the backwards accuracy, not the forwards. Doing the analysis to get half-ulp accuracy is really hard, and in fact you might need custom routines just for cpp_bin_float.

[cosurgi]

Thank you very much for your reply!

Note how these plots give a totally different way of understanding accuracy

yes, thank you. As I see it, the horizontal axis is the x argument and vertical axis is the ULP error drawn with blue dots. What is the green line though?

[...] adopted by MPFR, that for a representable x, f(x) is the correctly rounded value. This generally requires extra precision internally. Now, whether or not that's what you should do for cpp_bin_float is unclear to me.

I fully agree and understand the problems involved.

then you cast the input to a fixed-precision type of the requisite length [...]

You mean for example cpp_bin_float with twice the amount of decimal places? Yeah, that's what I'm doing right now :) I implemented there the RealHP<N> types using boost::mpl vector and mpfr or cpp_bin_float to chose the type from.

[...] perform the algorithm in fixed point

Which fixed-point type do you have in mind? I search multiprecision docs but I see no mention of a fixed point type.

but at the same time, what is the claimed accuracy in the docs?

yes. That's the important point. Write what kind of accuracy to expect, and all problems are solved. Maybe add in docs a more mention about how to obtain the error estimate in a small domain range in which the user is interested in (not the (-100,100) which I tested here ;).

I'm sorry, if I missed this part if it's in docs already.

[NAThompson]

What is the green line though?

The green line is +-|xf'(x)/f(x)|; the condition number of function evaluation.

You mean for example cpp_bin_float with twice the amount of decimal places?

Hopefully when you work out the analysis you don't necessarily use twice the number, just b more bits for some b.

Which fixed-point type do you have in mind? I search multiprecision docs but I see no mention of a fixed point type.

There is no fixed point class currently; I'm just stating the mechanism that is used to solve this problem. I've been agitating for fixed point for a while; but also have expended zero effort towards making it happen, so currently I have what I deserve, which is nothing.

[cosurgi]

I've been agitating for fixed point for a while; but also have expended zero effort towards making it happen, so currently I have what I deserve, which is nothing.

heheh. I also would like to see a fixed point type. We can muster only a finite amount of time though, so we do what we can!
